For 75 years Perkins has always taken the lead in the design and manufacture of high-performance diesel engines in the field. The continuous development programme of Perkins offers one of the most advanced and comprehensive ranges of purpose-built diesel and gas engines available today. Meanwhile, it commits to providing the optimum power solutions for diesel engines.
![400 Series 11.2 to 39.3 kVA](/upload/4079/o/3-3-2-perkins-series-diesel-engine_01.jpg)
1. 400 Series 11.2 to 39.3 kVA
a. 1.1 to 2.2 litre
b. In-line 3 and 4 cylinders
c. Naturally aspirated
The 400 series Perkins diesel engine, a significant evolution of the compact engine family, offers superior performance, with low emissions and low operating costs, all of which in a small efficient package.
![1100 Series 30 to 228 kVA](/upload/4079/o/3-3-2-perkins-series-diesel-engine_02.jpg)
2. 1100 Series 30 to 228 kVA
a. 3.3, 4.4 and 6.6 litre
b. In-line 3, 4 and 6 cylinder
c. Naturally aspirated
d. Turbocharged
e. Turbocharged and charge-cooled
1100 Series is a multigenerational product designed to provide an optimum range of power solutions for both areas with discharge limits or with no discharge limits.
![1000 Series 93 to 165 kVA](/upload/4079/o/3-3-2-perkins-series-diesel-engine_03.jpg)
3. 1000 Series 93 to 165 kVA
a. 6.0 litre
b. In-line 6 cylinders
c. Turbocharged
d. Turbocharged charge-cooled
Perkins advanced combustion technology makes the Perkins series diesel engine highly productive and fuel efficient. In addition, class leadership on the SAE maintainability index – a widely accepted means of comparing the serviceability of engines – and service intervals of up to 500 hours further minimizes operating costs of the diesel engines.
![1300 Series 189 to 275 kVA](/upload/4079/o/3-3-2-perkins-series-diesel-engine_04.jpg)
4. 1300 Series 189 to 275 kVA
a. 8.7 litre
b. In-line 6 cylinders
c. Turbocharged and charge-cooled
The 1300 series range features fully authorized electronic engines coupled with hydraulically actuated electronic controlled unit injectors, with clean, strong power, low noise and high fuel efficiency. This range of Perkins series diesel engines also boast proven reliability, remarkable design, and are fitted with low-cost roller cam and wet liners.
![2200 Series 350 to 500 kVA](/upload/4079/o/3-3-2-perkins-series-diesel-engine_05.jpg)
5. 2200 Series 350 to 500 kVA
a. 13 litre
b. In-line 6 cylinder
c. Turbocharged and charge-cooled
Developed on the basis of a proven industrial engine, this 13 litre turbocharged and charge cooled unit provides economic and reliable power at key modes in the industry. All the Perkins series diesel engines in this family meet the requirements of EPA/EC Stage 2 emission standards and are capable of meeting 1⁄2 TA Luft (1986) NOx levels.
![2500 Series 455 to 687 kVA](/upload/4079/o/3-3-2-perkins-series-diesel-engine_06.jpg)
6. 2500 Series 455 to 687 kVA
a. 15 litre
b. In-line 6 cylinder
c. Turbocharged and charge-cooled
The 2500 series builds on the strengths of the already very successful 2000 series family. This range of Perkins series diesel engines features exceptional power-to-weight ratio, resulting in exceptional fuel consumption. This engine offers power solutions to both emissions controlled and non-controlled areas.
![2800 Series 591 to 750 kVA](/upload/4079/o/3-3-2-perkins-series-diesel-engine_07.jpg)
7. 2800 Series 591 to 750 kVA
a. 18 litre
b. In-line 6 cylinders
c. Turbocharged and charge-cooled
A well proven family of 6 cylinder in-line engines is designed with particular focus on the standby sector. Developed from a proven heavy-duty industrial base, the 2800 Series Perkins diesel engines offer superior performance and reliability in economic operation with low exhaust emissions.
![4000 Series 585 to 2500 kVA](/upload/4079/o/3-3-2-perkins-series-diesel-engine_08.jpg)
8. 4000 Series 585 to 2500 kVA
a. 23 to 61 litre
b. In-line 6 and 8 cylinders
c. Vee 12 and 16 cylinders
d. Turbocharged and charge-cooled
A unique piston and cylinder design, incorporating an individually operated unit fuel injector, gives the Perkins 4000 series diesel engines ultra-low fuel consumption and emissions. The gas powered engines available in this range received the Queen Award for Environmental Achievement.
The delicate design and reliable performance of the Perkins series diesel engine have won Perkins a vast client base. What's more, with increasing development of its agency service and distribution network, Perkins has grown into a top ranking supplier of 4-2000 kW (5 - 2600 hp) diesel and gas engines. Ranging from 5 to over 2,600 hp, the Perkins series diesel engines are widely adopted by a large number of equipment manufacturers in the construction, power generation, materials handling, agricultural and general industrial markets.
Technical parameters Genset Power Selector Chart50HZ | Net Engine Output | Typical Generator Efficiency | Typical Power Factor | Typical Generating Set Output | 1500/1800 rev/min switchable | |||||||
Model | Baseload kWm | Prime kWm | Standby kWm | % | Baseload | Prime | Standby | |||||
kWe | Kva | kWe | kVA | kWe | kVA |
402D-05G | * | 7.7 | 8.5 | 86 | 0.8 | * | * | 6.6 | 8.3 | 7.3 | 9.1 |
403D-07G | * | 11.5 | 12 | 12.6 | 0.8 | * | * | 9.9 | 12.3 | 10.8 | 13.5 |
403D-11G | * | 16.5 | 18.1 | 18.1 | 0.8 | * | * | 14.2 | 17.7 | 15.6 | 19.5 |
403D-15G | * | 20.2 | 22.2 | 22.2 | 0.8 | * | * | 17.6 | 21.9 | 19.3 | 24.1 |
404D-22G | * | 29.7 | 32.7 | 32.7 | 0.8 | * | * | 26.5 | 33.1 | 29.1 | 36.4 |
403D-11G | * | 8.4 | 9.2 | 86 | 0.8 | * | * | 7.2 | 9 | 7.9 | 9.9 |
403D-15G | * | 12 | 13.2 | 87 | 0.8 | * | * | 10.4 | 13 | 11.4 | 14.3 |
404D-22TG | * | 18.4 | 20.3 | 88 | 0.8 | * | * | 16.2 | 20.3 | 17.8 | 22.3 |
1103A-33G | * | 24.3 | 26.7 | 90 | 0.8 | * | * | 21.8 | 27.3 | 24 | 30 |
1103A-33TG1 | * | 27.7 | 30.4 | 87 | 0.8 | * | * | 24 | 30 | 26.4 | 33 |
1103A-33TG1 | * | 41.3 | 45.6 | 87 | 0.8 | * | * | 36 | 45 | 39.7 | 49.6 |
1103A-33TG2 | * | 53.8 | 59.3 | 89 | 0.8 | * | * | 48 | 60 | 52.8 | 66 |
1104A-44TG1 | * | 58.4 | 64.3 | 89 | 0.8 | * | * | 52 | 65 | 57.2 | 71.5 |
1104A-44TG2 | * | 71.9 | 79.1 | 89 | 0.8 | * | * | 64 | 80 | 70.4 | 88 |
1104C-44TAG2 | * | 90.1 | 99.5 | 90 | 0.8 | * | * | 81.4 | 101.4 | 89.6 | 111.9 |
1006TG1A | * | 83 | 91.5 | 90 | 0.8 | * | * | 74.5 | 93 | 82.5 | 103 |
1006TG2A | * | 91 | 100 | 90 | 0.8 | * | * | 82 | 102.5 | 90 | 112.5 |
1006TAG | * | 121 | 133.5 | 90 | 0.8 | * | * | 109 | 136 | 120 | 150 |
1006TAG2 | * | 129.3 | 143 | 93 | 0.8 | * | * | 120 | 150 | 132 | 165 |
1106C-E66TAG4 | * | 158.4 | 175.5 | 93 | 0.8 | * | * | 147.3 | 184.1 | 163.2 | 204 |
1306C-E87TAG3 | 164 | 180 | 199 | 92 | 0.8 | 151 | 189 | 166 | 208 | 183 | 229 |
1306C-E87TAG4 | 179 | 198 | 217 | 92 | 0.8 | 165 | 205 | 182 | 228 | 200 | 250 |
1306C-E87TAG5 | 185 | 204 | 224 | 92 | 0.8 | 170 | 213 | 188 | 235 | 206 | 258 |
1306C-E87TAG6 | 198 | 217 | 239 | 92 | 0.8 | 182 | 228 | 200 | 250 | 220 | 275 |
2206A-E13TAG2 | * | 305 | 349 | 92 | 0.8 | * | * | 280 | 350 | 320 | 400 |
2206A-E13TAG3 | * | 349 | 392 | 92 | 0.8 | * | * | 320 | 400 | 360 | 450 |
2506A-E15TAG1 | * | 396 | 434 | 92 | 0.8 | * | * | 364 | 455 | 400 | 500 |
2506A-E15TAG2 | * | 435 | 478 | 92 | 0.8 | * | * | 400 | 500 | 440 | 550 |
2806A-E18TAG1A | * | 522 | 574 | 92 | 0.8 | * | * | 480 | 600 | 528 | 660 |
2806A-E18TAG2 | * | 565 | 609 | 92 | 0.8 | * | * | 520 | 650 | 560 | 700 |
4006-23TAG2A | 505 | 632 | 695 | 95 | 0.8 | 480 | 600 | 600 | 750 | 660 | 825 |
4006-23TAG3A | 540 | 679 | 760 | 94 | 0.8 | 512 | 640 | 640 | 800 | 720 | 900 |
4008TWG2 | 560 | 710 | 782 | 95 | 0.8 | 532 | 665 | 675 | 843 | 743 | 929 |
4008TAG | 566 | 715 | 787 | 95 | 0.8 | 538 | 672 | 679 | 849 | 748 | 935 |
4008TAG1A | 606 | 767 | 844 | 95 | 0.8 | 576 | 720 | 728 | 911 | 802 | 1002 |
4008TAG2A | 681 | 861 | 947 | 95 | 0.8 | 647 | 809 | 818 | 1022 | 900 | 1125 |
4012-46TAG0A | 842 | 1053 | 1158 | 95 | 0.8 | 800 | 1000 | 1000 | 1250 | 1100 | 1375 |
4012-46TWG2A | 833 | 1055 | 1166 | 95 | 0.8 | 791 | 989 | 1002 | 1253 | 1108 | 1385 |
4012-46TWG3A | 909 | 1149 | 1263 | 95 | 0.8 | 864 | 1079 | 1092 | 1364 | 1200 | 1500 |
4012-46TAG1A | 909 | 1148 | 1263 | 95 | 0.8 | 864 | 1080 | 1091 | 1364 | 1280 | 1500 |
4012-46TWG4A | - | 1254 | 1342 | 96 | 0.8 | - | - | 1200 | 1500 | 1325 | 1600 |
4012-46TAG2A | 1005 | 1267 | 1395 | 95 | 0.8 | 955 | 1194 | 1204 | 1505 | 1504 | 1656 |
4012-46TAG3A | 1200 | 1440 | 1583 | 95 | 0.8 | 1140 | 1425 | 1368 | 1710 | 1622 | 1880 |
4016-61TRG1 | 1178 | 1558 | 1684 | 96 | 0.8 | 1120 | 1400 | 1480 | 1850 | 1600 | 2000 |
4016TAG1A | 1219 | 1537 | 1690 | 96 | 0.8 | 1170 | 1463 | 1476 | 1844 | 1622 | 2028 |
4016-61TRG2 | 1347 | 1684 | 1894 | 96 | 0.8 | 1280 | 1600 | 1600 | 2000 | 1800 | 2250 |
4016TAG2A | 1362 | 1715 | 1886 | 96 | 0.8 | 1307 | 1634 | 1646 | 2058 | 1811 | 2263 |
4016-61TRG3 | 1500 | 1875 | 2083 | 96 | 0.8 | 1440 | 1800 | 1800 | 2250 | 2000 | 2500 |
4006-23TRS1† | 322 | - | - | 95.4 | 1 | 307 | 307 | - | - | - | |
4006-23TRS2† | 393 | - | - | 95.4 | 1 | 375 | 375 | - | - | - | |
4008-30TRS1† | 447 | - | - | 95 | 1 | 425 | 425 | - | - | - | |
4008-30TRS2† | 526 | - | - | 95 | 1 | 500 | 500 | - | - | - | |
4012TESI† | 632 | - | - | 95 | 1 | 600 | 600 | - | - | - | |
4016-61TRS1† | 912 | - | - | 96 | 1 | 875 | - | - | - | - | - |
4016-61TRS2† | 1042 | - | - | 96 | 1 | 1000 | - | - | - | - | - |
60HZ | Net Engine Output | Typical Generator Efficiency | Typical Power Factor | Typical Generating Set Output | 1500/1800 rev/min switchable | |||||||
Model | Baseload kWm | Prime kWm | Standby kWm | % | Baseload | Prime | Standby | |||||
kWe | Kva | kWe | kVA | kWe | kVA | |||||||
1800 rev/min (3.9 kWe to 1504 kWe) | ||||||||||||
402D-05G | * | 4.5 | 5 | 86 | 0.8 | * | * | 3.9 | 4.9 | 4.3 | 5.3 | |
403D-07G | * | 6.6 | 7.3 | 86 | 0.8 | * | * | 5.7 | 7.1 | 6.3 | 7.8 | |
403D-11G | * | 10.4 | 11.4 | 87 | 0.8 | * | * | 9 | 11.3 | 9.9 | 12.4 | · |
403D-15G | * | 14.4 | 15.8 | 88 | 0.8 | * | * | 12.6 | 15.8 | 13.9 | 17.4 | · |
404D-22G | * | 21.7 | 23.9 | 89 | 0.8 | * | * | 19.3 | 24.2 | 21.3 | 26.6 | · |
404D-22TG | * | 28.8 | 31.7 | 89 | 0.8 | * | * | 25.6 | 32.1 | 28.2 | 35.3 | |
404D-22TAG | * | 31.5 | 34.7 | 89 | 0.8 | * | * | 28.4 | 35.5 | 31.2 | 39 | |
1103A-33G | * | 32.2 | 35.4 | 87 | 0.8 | * | * | 27.9 | 34.9 | 30.6 | 38.2 | · |
1103A-33TG1 | * | 48.8 | 53.9 | 87 | 0.8 | * | * | 42.5 | 53.1 | 46.9 | 58.7 | · |
1103A-33TG2 | * | 61.2 | 66.4 | 89 | 0.8 | * | * | 54.5 | 68.1 | 60.1 | 75.1 | · |
1104A-44TG1 | * | 68.6 | 75.5 | 89 | 0.8 | * | * | 60.8 | 76 | 66.9 | 83.6 | · |
1104A-44TG2 | * | 82 | 90.2 | 89 | 0.8 | * | * | 73 | 91.3 | 80.3 | 100.3 | · |
1006TG1A | * | 96.5 | 106.5 | 90 | 0.8 | * | * | 87 | 109 | 96 | 120 | |
1006TG2A | * | 107 | 118 | 90 | 0.8 | * | * | 96.5 | 120.5 | 106 | 132.5 | |
1006TAG | * | 134 | 147 | 90 | 0.8 | * | * | 120.5 | 151 | 132.5 | 165.5 | · |
1106C-E66TAG2 | * | 138.4 | 155.3 | 92 | 0.8 | * | * | 127.3 | 159.2 | 142.9 | 178.6 | · |
1106C-E66TAG3 | * | 146.4 | 163.4 | 92 | 0.8 | * | * | 136.1 | 170.1 | 152 | 190 | · |
1106C-E66TAG4 | * | 177.3 | 196.3 | 92 | 0.8 | * | * | 164.9 | 206.1 | 182.6 | 228.2 | · |
1106D-E66TAG2 | * | 136.6 | 153.6 | 92 | 0.8 | * | * | 125 | 156 | 140 | 175 | |
1106D-E66TAG3 | * | 142.4 | 159.4 | 92 | 0.8 | * | * | 135 | 169 | 150 | 188 | |
1106D-E66TAG4 | * | 173.7 | 192.3 | 92 | 0.8 | * | * | 160 | 200 | 175 | 219 | |
1306C-E87TAG3 | 182 | 201 | 220 | 92 | 0.8 | 167 | 209 | 185 | 231 | 202 | 253 | · |
1306C-E87TAG4 | 194 | 213 | 235 | 92 | 0.8 | 178 | 223 | 196 | 245 | 216 | 270 | · |
2206A-E13TAG5 | * | 349 | 381 | 92 | 0.8 | * | * | 320 | 400 | 350 | 438 | · |
2206A-E13TAG6 | * | 381 | 435 | 92 | 0.8 | * | * | 350 | 438 | 400 | 500 | · |
2506A-E15TAG3 | * | 446 | 490 | 92 | 0.8 | * | * | 410 | 513 | 450 | 563 | · |
2506A-E15TAG4 | * | 495 | 543 | 92 | 0.8 | * | * | 455 | 569 | 500 | 624 | · |
2506C-E15TAG4# | - | - | 597 | 92 | 0.8 | - | - | - | - | 550 | 687 | |
2806A-E18TAG1A | * | 543 | 598 | 92 | 0.8 | * | * | 500 | 625 | 550 | 687 | · |
2806A-E18TAG3 | * | 592 | 652 | 92 | 0.8 | * | * | 545 | 681 | 600 | 750 | · |
4006-23TAG2A | 511 | 638 | 702 | 94 | 0.8 | 480 | 600 | 600 | 750 | 660 | 825 | |
4008TWG2 | 534 | 684 | 756 | 95 | 0.8 | 507 | 634 | 650 | 812 | 718 | 898 | |
4008TAG | 564 | 712 | 784 | 95 | 0.8 | 536 | 670 | 676 | 846 | 745 | 931 | |
4006-23TAG3A | 570 | 715 | 795 | 95 | 0.8 | 540 | 675 | 675 | 844 | 750 | 938 | |
4008TAG1 | 584 | 744 | 821 | 95 | 0.8 | 555 | 694 | 707 | 884 | 780 | 975 | |
4008TAG2 | 659 | 838 | 924 | 95 | 0.8 | 626 | 783 | 796 | 995 | 878 | 1097 | |
4012-46TWG2A | 833 | 1055 | 1166 | 95 | 0.8 | 791 | 989 | 1002 | 1253 | 1108 | 1385 | |
4012-46TWG3A | 909 | 1149 | 1263 | 95 | 0.8 | 864 | 1079 | 1092 | 1364 | 1200 | 1500 | |
4012-46TAG1A | 914 | 1153 | 1267 | 95 | 0.8 | 868 | 1085 | 1095 | 1369 | 1204 | 1505 | |
4012-46TWG4A | - | 1254 | 1342 | 96 | 0.8 | - | - | 1200 | 1500 | 1280 | 1600 | |
4012-46TAG2A | 1009 | 1272 | 1399 | 95 | 0.8 | 959 | 1199 | 1208 | 1510 | 1329 | 1669 | |
4012-46TAG3A | 1200 | 1440 | 1583 | 95 | 0.8 | 1140 | 1425 | 1368 | 1710 | 1504 | 1880 | |
1200 rev/min (592 kWe to 1478 kWe) | ||||||||||||
4008TAG1 | 491 | 623 | 686 | 95 | 0.8 | 466 | 583 | 592 | 740 | 652 | 815 | |
4008TAG2 | 547 | 693 | 763 | 95 | 0.8 | 520 | 650 | 658 | 823 | 725 | 906 | |
4016TAG | 908 | 1146 | 1263 | 96 | 0.8 | 872 | 1091 | 1100 | 1375 | 1212 | 1515 | |
4016TAG2 | 1108 | 1400 | 1540 | 96 | 0.8 | 1063 | 1329 | 1344 | 1680 | 1478 | 1848 | |
Gas Power 1200 rev/min (576 kWe) | ||||||||||||
4012TESI† | 600 | - | - | 96 | 1 | 576 | 576 | - | - | - | - |
* For switchable engines, please consult with your local Perkins representative.
The engine is available as Electro Unit only.
Notes:
– All ratings are for guidance only, please refer to the specific engine technical data sheet for final powers.
– Perkins conditions of sale apply.
– Electrical output is based on typical generator efficiency and is for guidance only.
– All ratings data based on operation under ISO 8528-1, ISO 3046, DIN6271 conditions using typical fan sizes and drive ratios. Performance tolerance quoted by Perkins is ± 5%.
– Baseload Power = Power available for continuous full load operation. An overload of 10% permitted for one hour in every twelve hours of operation.
Please Note: No overload is permitted on 4000 Series.
– Prime Power = Power available at variable load in lieu of main power network (please refer to the engine Technical Data Sheet for engine load factors). An overload of 10% permitted for one hour in every twelve hours of operation.
– Standby Power = Power available at a variable load in the event of a main power network failure up to a maximum of 500 hours per year. No overload is permitted.
– Emergency Standby Power = Power available in the event of a main power network failure, up to maximum of 200 hours per year which may be run continuously. Load factor may be up to 70% of the Emergency Standby Power rating. No overload is permitted.
DIESEL Model | Length (A) | Height (B) | Width (c) | Length (D) | ElectropaK Dry Weight (kg) |
402D-05G | |||||
403D-07G | 480 | 528 | 371 | - | 71 |
403D-11G | 776 | 700 | 449 | - | 129 |
403D-15G | 820 | 791 | 476 | - | 197 |
404D-22G | 915 | 840 | 477 | - | 242 |
404D-22TG | 988 | 969 | 588 | - | 260 |
404D-22TAG | 1073 | 997 | 700 | - | 300 |
1103A-33G | 1029 | 951 | 629 | 912 | 412 |
1103A-33TG1/TG2 | 1049 | 951 | 634 | 928 | 420 |
1104A-44TG1/TG2 | 1241 | 951 | 629 | 1046 | 463 |
1103C-33G2/G3 | 1045 | 951 | 631 | 928 | 329 |
1103C-33TG2/TG3 | 1048.8 | 951 | 634 | 928 | 420 |
1104C-44TG2/TG3 | 1239 | 951 | 614.8 | 1045.7 | 401 |
1104D-44TG1 | 1238 | 967 | 637 | - | 474 |
1104C-44TAG1/TAG2 | 1259 | 966 | 721 | 1121 | 401 |
1006TG1A | 1559 | 1124 | 709 | 1378 | 542 |
1006TG2A | 1559 | 1124 | 709 | 1378 | 586 |
1006TAG | 1685 | 1065 | 773 | 1450 | 586 |
1006TAG2 | 1685 | 1065 | 773 | 1450 | 586 |
1104D-E44TG1 | 1281 | 940 | 708 | - | 483 |
1104D-E44TAG1/TAG2 | 1357.7 | 1090.7 | 749.6 | 1067.7 | 465 |
1106C-E66TAG2/TAG3 | 1728.3 | 1140.4 | 779.8 | 1413.8 | 788 |
1106C-E66TAG4 | 1763.2 | 1140.4 | 788.3 | 1421 | 788 |
1106D-E66TAG2/TAG3 | 1728.3 | 1140.4 | 779.8 | 1413.8 | 788 |
1106D-E66TAG4 | 1763.2 | 1140.4 | 788.3 | 1421 | 788 |
1306C-E87TAG3/TAG4/TAG5/TAG6 | 1822 | 1369 | 875 | 1539 | 895 |
2206A-E13TAG2/TAG3/TAG5/TAG6 | 2410 | 1725 | 1120 | - | 1478 |
2206C-E13TAG2/TAG3 | 2410 | 1725 | 1120 | - | 1478 |
2206D-E13TAG2/TAG3 | 2410 | 1725 | 1120 | - | 1478 |
2306A-E14TAG2/TAG3 | 2422 | 1614 | 1107 | 2029 | 1690 |
2306C-E14TAG2/TAG3 | 2657 | 1718 | 1120 | - | 1633 |
2506A-E15TAG1/TAG2/TAG3/TAG4 | 2657 | 1718 | 1120 | - | 1633 |
2506C-E15TAG1/TAG2/TAG3/TAG4 | 2657 | 1718 | 1120 | - | 1633 |
2506D-E15TAG1 | 2657 | 1718 | 1120 | - | 1633 |
2806A-E18TAG1A/TAG2/TAG3 | 2545 | 1807.5 | 1536 | 2050 | 2050 |
2806C-E18TAG1A/TAG3 | 2545 | 1807.5 | 1536 | 2050 | 2050 |
4006-23TAG2A/TAG3A | 3027 | 1964 | 1706 | 2414 | 2524 |
4008TAG | 3780 | 2193 | 1630 | 3129 | 3730 |
4008TAG1/TAG2 | 3935 | 2258 | 1870 | 3281 | 4360 |
4008TAG1A/TAG2A | 3852 | 2067 | 2046 | 2921 | 4270 |
4008TWG2 | 2890 | 1772 | 1585 | 2201 | 3350 |
4012-46TAG1A/TAG2A/TAG3A | 3971 | 2260 | 2192 | 3339 | 4400 |
4012-46TWG2A/TWG3A/TWG4A | 3714 | 2255 | 1978 | 2930 | 5283 |
4016TWG2 | 4510 | 3149 | 2775 | 3872 | 8240 |
4016TAG1A/TAG2A | 4460 | 3239 | 2775 | 3827 | 8010 |
4016TEG1/TEG2 | 3450 | 2115 | 1410 | 2812 | 6000 |
4016-61TRG/1/2/3 | 3302 | 1723 | 2128 | - | 5570 |
GAS Model | Length (X) | Height (Y) | Width (Z) | Engine Dry Weight |
4006-23TRS1/TRS2 | 2242 | 1787 | 1633 | 1650 |
4008-30TRS1/TRS2 | 2658 | 1782 | 1633 | 3350 |
4012TESI | 2650 | 1860 | 1895 | 4680 |
4016-61TRS1/TRS2 | 3192 | 1969 | 1737 | 5820 |
All dimensions are given in mm. All weights are given in kg. Data is approximate only. Perkins reserves the right to change without prior notice.
Emissions Regulations
Perkins can supply engines for power generation applications which satisfy the requirements of TA Luft, 1⁄2 TA Luft regulations andUS EPA and EU off-highway legislation.
Please contact your local Perkins representative for information on specific engine ratings.
A leading Perkins series diesel engine supplier in China, Guangdong RISE Power Equipment Inc. has received ISO9001:2000 certification due to its operation in strict accordance with international standards. In addition to the Perkins series diesel engine, we also provide XinChai series diesel engine, SDEC diesel engine, and a range of generator sets, such as Caterpillar Olympian generator set, Yanmar generator set, Deutz generator set, and John Deere generator set, to name a few. With reliable quality, stable performance, easy operation, safety and durability, our products are highly sought after by a vast number of customers in both domestic and overseas markets. Located in Guangzhou, our company has access to convenient air, sea and land transportation, which helps to lower our transportation cost but save the shipping charges of our customers as well. If you are interested in our diesel engines or generator sets, please feel free to contact us. Staffs at RISE Power look forward to working with you.
